ABSTRACT
The
SATMODE system provides a revolutionary low cost solution for low data rate
transmission over satellite, in
support of interactive
television services. This low cost is
achieved through the introduction of
constant envelope modulation,
and efficient channel coding
techniques. The SATMODE system
specifications will be proposed as a
new Cenelec standard in Europe .
The lac k of an efficient and scalable return path has always limited
true interactivity over
satellite TV. Remote interactivity is
the key element
needed for the
continuation of growth
of digital television through the
introduction of new services. This interactivity requires a scalable,
secured, always on permanent instantaneous connectivity.SATMODE answers this
need, allowing the connection of TV
consumers individually, both ways with their iTV content providers, with other
consumers, with other infrastructures
(GSM and internet) in real time,
at any time, all the time. The main characteristics of SATMODE are: always on connectivity, packet transmission, ability to carry IP, bi
t rate adaptability (1 to 64 kbit/s), random
access scheme, flexible air-interface. Although compatible
with existing satellites, SATMODE is
designed to be
ready for new generations of
space segments. The new technology under SATMODE
provides interactivity for
satellite television. Previously, interactivity
for satellite television was
only possible through terrestrial return channels
such as phone connections
from a viewer's STB
(set-top box) to the TV content broadcast.
INTRODUCTION
SATMODE is a satellite return link system providing 'always-on'
connectivity between digital TV set topboxes -- the interactive version of
commercial satellite TV receivers --The SATMODE system is set to enable
permanent, real time responses by millions of TV viewers to content provider's
programmes. It will also allow additional services such as SMS, televoting,
management of personal video recorders, access control, pay per view and other
impulse transactions. ESA is committed to support developments that reduce the
risk to implement commercially viable satcom innovations. In particular, the
user terminal is one of the most critical factors for success in the consumer
market. SATMODE is a prominent example of the special attention that ESA is
devoting to user terminals and applications. Easily integrated into an existing
or new, basic or DVR-powered, satellite TV set-top box, SATMODE is designed to
enable broadcasters to deliver truly personalized, interactive and on-demand
services directly to individual subscribers. Whether it’s in the hands of
millions of voting American Idol fans, chatting friends and family members
worldwide, or movie buffs ordering the latest release on-demand, the
scalability of SATMODE would allow the transactions to be completed without
delay. SATMODE is a low-cost always on transmission technology, designed to
enable broadcasters and DBS providers to personalize the television experience
for their subscribers. Services based on this technology can be easily
integrated into existing or
New, basic and DVR-based set-top boxes, and will be offered with a
turn-key option for service providers that prefer to leave the back office
management to SATMODE.
New
proposals for highly immersive interactive TV, telemedicine and medical
education for travelers, tele-psychiatry, e-government for a
public-administration regional service, Internet access on high-speed trains,
and dissemination of information to cars using satellite and WiFi have been
selected as key areas for innovation’s is progressively addressing thematic
areas that require specifications to improve the uptake of commercially viable
initiatives. These areas - so far Broadband Access to All, Interactive
TV,Tele-Home Care, Security/Civil Protection, Broadband to
Trains,Infopoverty/Capacity Building - will host mid-sized Pilot Projects in
the next phase of the Telecommunications Programmed. applications. The
end-to-end system is currently undergoing final integration and validation and
will soon be made available to application developers. SATMODE is being
developed by consortium led by SES Astra, including Newtec,Thomson, NDS, STMicroelectronics
and Spacebridge.
SATMODE
WORKING
The SATMODE network consists of the terminals installed at the users
homes, and a hub station installed at the broadcasters site.
SATMODE users need:
• an antenna
• the SATMODE interactive
LNB (iLNB), which includes a low power transmitter (in addition to the normal
low noise block converter function)
• a digital television
receiver and decoder (Set-Top-Box) with interactive application software
(interactive application client)
• the SATMODE satellite
modem (Add On Box)
The SATMODE modem
function can also be build into the set top box (interactive Set Top Box or
iSTB).
The installation at the
broadcaster’s site consists of:
• an antenna
• the SATMODE hub which
receives the radio signals from the terminals and extracts the data and which
transmits the digital television signals the broadcast centre where television
programmes and associated data are distributed interactive application servers
that process the data send by the terminals
The SATMODE hub station
can be scaled according to the number of users in the networks, by adding
capacity blocks. These capacity blocks are called ‘blades’. Typical capacity
for the return channel .
INTERNAL
STRUCTURE
Understanding modem's work is to look at its internal structure. A block
diagram of a generic satellite modem is shown on the image. Almost all parts
are optional. After a digital-to-analog conversion in the transmitter the signal passes through
a reconstruction filter Then its frequency is converted if needed. The purpose
of the analog tract in the receiver is to convert signal's frequency, to adjust
its power via an automatic gain control circuit and to get its complex envelope
components.
The input signal for the
analog tract is at the intermediate frequency or in the L-band in the second
case it must be firstly converted to IF. Then the signal is either sampled or
processed by the four-quadrant multiplier which produces the complex envelope
components (I,Q) through multiplying it by the heterodyne frequency.
See Super heterodyne receiver
At last the signal passes through an
anti-aliasing filter and sampled (digitized).
Main article: Digital demodulator title
A digital modulator transforms a digital stream into a radio signal on
Intermediate frequency (IF). A modulator is generally a much simpler device
than a demodulator, because it doesn't have to recover symbol and carrier
frequencies.
A demodulator is one of the most important parts of the receiver. The exact
structure of the demodulator is defined by a modulation type. However, the
fundamental concepts are similar. Moreover, it is possible to develop a
demodulator which can process signals with different modulation types.
Digital demodulation implies that a symbol clock (and, in most cases, an
intermediate frequency generator) at the receiving side have to be synchronous
with those at the transmitting side. This is achieved by the following two
circuits:
·timing recovery circuit
determining the borders of symbols;
·carrier recovery circuit
which determines the actual meaning of each symbol.
There are modulation types (like frequency shift keying that can be
demodulated without carrier recovery (noncoherent) demodulation but this method is generally worse
There are also additional components in the demodulator such as the
Intersymbol interference .If the analog signal was digitized without a
four-quadrant multiplier, the complex envelope has to be calculated by a
digital complex mixer.Sometimes a digital automatic gain controlcircuit is
implemented in the demodulator
FEC coding
Error correction techniques are
essential for satellite communications, because, due to satellite's limited
power a signal to noise ratio at the receiver is usually rather poor. Error
correction works by adding an artificial redundancy to a data stream at the
transmitting side, and using this redundancy to correct errors caused by noise
and interference.
A FEC encoder applies an error correction code to the digital stream,
adding redundancy.
A FEC decoder decodes the Forward error correction code that is used in
the specific signal. For example, Digital video broadcasting standard defines a
concatenated code consisting of inner convolutional (standard NASA code,
perforated, with rates 1 / 2, 2 / 3, 3 / 4, 5 / 6, 7 / 8), interleaving and
outer Reed-Solomon code (block length: 204 bytes, information block: 188 bytes,
can correct up to 8 bytes in the block).
Differential coding
Main article: Differential coding
There are several modulation types (such as PSK and QAM that have a phase
ambiguity that is, a carrier can be restored in different ways. Differential
coding is used to resolve this ambiguity.When differential coding is used, the
data are deliberately made to depend not only on the current symbol, but also
on the previous one.
Scrambling
Main article: Scrambler (randomizer)
Scrambling is a technique used to
randomize a data stream to eliminate long '0'-only and '1'-only sequences and
to assure energy dispersal. Long '0'-only and '1'-only sequences create
difficulties for timing recovery circuit. Scramblers and descramblers are
usually based on linear feedback shift registers
A scrambler randomizes the data stream to be transmitted. Descrambler
restores the original stream from the scrambled one.
Scrambling shouldn't be confused with encryption, since it doesn't
protect information from intruders.
Multiplexing
A multiplexer transforms several digital stream into one stream.
Generally, a demultiplexer is a device which transforms one multiplexed
data stream to several streams which it consists of. Satellite modem doesn't
have so many outputs, so a demultiplexer here performs a [[drop and
insert|drop] operation, allowing to choose channels that will be transferred to
output.
A demultiplexer achieves this goal by maintaining a frame
synchronization.
a.SATMODE Return Link Technical Features
The SATMODE return link is highly programmable and has the
following main technical features:
• continuous phase
modulation (GMSK, MSK and quaternary MSK are supported),
• symbol rate from 4
ksymbols/s to 128 ksymbols/s
• MF-TDMA burst
transmission
• performing channel
coding for data protection (supports several types of turbo-coding and coding
rates)
• code rates ½ to 5/6
• Medium Access Protocol
(MAC) = Aloha protocol, with selective repeat retransmission
• MAC packet size of 66
bytes
• MAC protocol is
transparent to
network layer protocols
• rain fade mitigation by
adaptive rate and coding, algorithm resides in terminal
• compatible with
transmission in Ka band, Ku band or other bands
• low transmit powers
(100 to 300mW).small antennas (~60cm)
To reach that goal and nevertheless keep full interoperatibility of terminals, SATMODE uses a fully specified waveform toolbox.
Each building block has a well-defined space of operation and can be used
without limitation in this space.
b.The building blocks of the
SATMODE toolbox
·Binary or quaternary CPM.
·Symbol Rate: 2 kHz to 128
kHz
·Programmable phase filter
for CPM modulations (GMSK being a specific case)
·Flexible Turbo or
Turbo-like
·Programmable interleavers
(3)
·Programmable constituent
codes with bypass possibilities (2)
·Programmable Unique Word
structure
·Tables extraction from a
DVB TS (DVB-S or DVB-S2 broadcast)
All the parameters are sent by the
HUB through DVB tables, even allowing changes during operation:
·FCT: Sprectrum
organisation in Carrier Groups
·FAT: Spectrum Allocation
to services
Signalisation information sent to specific terminals is also embedded in
DVB tables (SMT tables).
The terminal is fully defined: it must be able to play the complete
waveform space. The HUB usually only implements one scheme and sends the tables
to the terminals to instruct them to play that scheme.
SATMODE is a
joint program to develop a low-cost two-way communication channel by satellite
for the satellite TV users
Connecting
TV consumers individually, both ways:
·With their content providers,
·With other consumers, on TV,
·With other infrastructures (GSM, internet),
·In real time,
·At any time,
·All the time.
FEATURE’S
OF SATMODE
The continuous phase modulation technique has been selected
in SATMODE because it allows using saturated power amplifiers and frequency
multiplication in the iLNB. This means no automatic level control or phase
locked loops are necessary in the iLNB and the cost of the iLNB can be kept
very low.
The flexible channel coding provided by SATMODE allows to
profit from the latest technical developments in this field. Turbo-codes are
available, that allow to operate with very low signal to noise ratios (for
example required Eb/N0 = 3.7dB for code rate ½). This means that very small
antennas and very low transmit powers can be used which again allow to keep the
cost of the terminal down.
SATMODE main design drivers are:
Ultra low cost satellite return link for short & frequent
interactions
Always-on , responsive, always connected, stand-alone and dedicated;
·
For both Pay-TV and FTA (Free-To-Air) mass markets;
·
Cheapest CPE and cost of ownership possible; < 50 Euros
extra;
·
Low and flexible bit rate; average: few bit/s; short packets;
·
Compatibility with next generation space segment;
·
Replacement of the PSTN modems for targeted iTV applications;
·
Allow for shared ODUs (SMATV),
·
User-friendly installation (= 'regular' digital DTH
installation),
·
Inter-working with existing terrestrial return channel
solutions,
·
Compliance to environmental, legal & regulatory
framework,
·
MHP support.
MODEM
LAYERS
A "modem" stands for "modulator-demodulator". A
satellite modem's main function is to transform an input bit stream to a radio
signal and vice versa. There are some devices that include only a demodulator
(and doesn't comprise any modulator) that are also referred to as
"satellite modems". These devices are used in satellite Internet
access.
There is a wide range of satellite
modems from cheap devices for home internet
access to expensive multifunctional
equipment for enterprise use.
A satellite modem is not the only device needed to establish a
communication channel. Other equipment that is essential for creating a
satellite link. Data to be transmitted are transferred to a modem from Data
terminal equipment .
The modem usually has Intermediate frequency IF) output (that is, 50-200
MHz), however, sometimes the signal is modulated directly to L-band .In most
cases frequency has to be converted using an up converter before amplification
and transmission.
Modulated signal
is a sequence of symbols, pieces of data represented by a corresponding signal
state, e.g. a bit or a few bits, depending upon a modulation. Recovering a
symbol clock (making a local symbol clock generator synchronous with the remote
one) is one of the most important tasks of a demodulator. Similarly, a signal
received from a satellite is firstly down converted this is done by a Low-noise
block converter ( LNB)then demodulated by a modem, and at last handled by data
terminal equipment. The LNB is usually powered by the modem through the signal
cable with 13 or 18 V DC
The modem layer is specified by a proposed CENELEC standard (prEN50478).
The SATMODE design having led to this specification was optimized for the
iTV case.The choice of constant envelope modulations was made to minimize the
terminal cost. Thanks to this property, very low cost ODUs operating at full
saturation and in non-linear mode can be used.
The moderate bit rates of SATMODE allow to
use very low power transmitters (typically 100 mW), keeping the cost compatible
with the mass-market.The selected access scheme -slotted ALOHA- is efficient on
iTV traffic and very easy to scale up to a very high number of terminals only
sending a few packets from time to time.
The SATMODE modem
specification aims at fully specifyinspecifying the behavior SATMODE modem
function used in a terminal.To increase the applicability and the probability
of commercial success of SATMODE, it was decided to design SATMODE as a system
usable with existing space segments and ready for future satellites improved for
point-to-point application.
SATELLITE CAPACITY
Typically a wide downlink coverage area in Ku band is used for DTH TV
broadcast. The return channel can be implemented with a wide uplink coverage
(Ku band) or spot beams (Ka band)
The satmode return channel is a Aloha system with typical spectral
efficiency of about 8Hz/data bit.
Required return channel transponder capacity is mainly driven by
applications such as televoting, where a large number of users need to send
data in a short period.
For example in a network with 300000 users participating to a televoting
that spans 5 minutes the required transponder bandwidth is calculates as
follows:
·
nr of votes per second = 300000/300 = 1000
·
nr of data bytes = 64
·
aggregated bit rate in kbits/s = 64 x8 x1000/1000 = 512
·
required transponder bandwidth in kHz = 8 x 512 = 4096
Forward link data generated by the satmode network are multiplexed into
the TV multiplex (DVB-S), required bandwidth is typically 10% of the required
return link bandwidth
BENEFITS
OF SATMODE
SATMode’s
expected main benefits:
1. Scailability
SATMODE is very scalable to
address a mass market of several
Millions of users,Among them, the messages are sent through SATMODE without any establishment time with a total transmission time lower than a few seconds.The system is scalable up to the complete DTH market and is designed to minimize the terminal cost.The system is scalable up to the complete DTH market and is designed to minimize the terminal cost. Major Benefits Scalable addressing for a market of several millions of users per national market Availability to all users within the satellite footprint Always-on, permanent and instantaneous connectivity Minimal costs of terminals and communication Enhanced security "Simple to install Services Transactional (Push or Pull VOD, Music, Betting) Personal Communication: Chat, SMS, e-mail Tele-Voting, Polls, Play-along, Quiz Games: standalone or multiplayer Interactive advertising Home Shopping Personal Data Consultation/banking Internet Services
Millions of users,Among them, the messages are sent through SATMODE without any establishment time with a total transmission time lower than a few seconds.The system is scalable up to the complete DTH market and is designed to minimize the terminal cost.The system is scalable up to the complete DTH market and is designed to minimize the terminal cost. Major Benefits Scalable addressing for a market of several millions of users per national market Availability to all users within the satellite footprint Always-on, permanent and instantaneous connectivity Minimal costs of terminals and communication Enhanced security "Simple to install Services Transactional (Push or Pull VOD, Music, Betting) Personal Communication: Chat, SMS, e-mail Tele-Voting, Polls, Play-along, Quiz Games: standalone or multiplayer Interactive advertising Home Shopping Personal Data Consultation/banking Internet Services
2. Flexibility
Considering this objective, it was considered as mandatory to have
built-in flexibility in terminals deployed today and ready for the
future.
This flexibility allows SATMODE to be used in extreme scenarios by
adjusting the modem parameters:
·Very power limited
scenarios (it’s the case for most VSAT Ku-band satellites)
·Aggressive multi-beam
space segment, targeting high spectral efficiency.
3.
Interactivity
SATMODE represents a significant innovation in the support of a new tier
of interactive applications via DTH and places these services on par with the
growing interactive services offered via cable,” The lack of an efficient
return path has always limited true interactivity over satellite TV,” SATMODE
will remove this major obstacle and will help accelerate wide deployment of
interactive television. This is good news for the consumer, for the advertiser,
and for the content creator. Remote interactivity is the key element needed for
the continued growth of digital television. Indeed, there is a strong demand
for TV enhancements using interactivity to allow the introduction of new
services. This interactivity requires a secured, always-on, permanent,
instantaneous connectivity, scalable to millions of viewers. The purpose of SATMODE is
to connect TV consumers individually, both ways with their content providers,
with other TV consumers and with other infrastructures, in real time, at any
time, all the time. SATMODE is an ultra low cost interactive TV solution via
satellite, targeting the mass-market through consumer products.
4.Real-time
voting
SATMODE, an innovative technology designed to support real-time voting,
chatting, messaging, commerce, video-on-demand, and other exciting applications
at the remote control fingertips of DBS consumers worldwide,
·The SATMODE system is set
to enable permanent, real time responses by millions of TV viewers to content
provider’s programmes. It will also allow additional services such as SMS,
televoting, management of
personal video recorders, access
control, pay per view and other impulse transactions.
·home shopping
·impulse pay-per-view
·SMS, chat and emails from
the TV interface, either synchronized with a show or as one TV to TV or GSM
phone connections
·Interactive games and
gambling.
·tele-voting
5.Low
cost
ASTRA’s ability to provide satellite-based interactivity on a large
scale, and at a low cost, will further encourage the development of additional
interactive services.
Due to the nature of iTV traffic, SATMODE is also very competitive in
terms of communication costs and thus in terms of total cost of ownership.
Viewers will need SATMODE enabled set-top boxes and a transmit/ receive feed in
order to use SATMODE services. This equipment will be made available by the
pay-TV provider, or acquired at attractive prices. The antenna equipped with
the new feed will be easy to install and will use the existing cable and 60 cm
reflector. Market research shows that viewers who have ASTRA satellite dishes
are statistically more interested in new technologies than other TV viewers and
so can bring high growth
6. SATMODE provides 100% coverage (this is
not the
case for xDSL or ISDN or Mobile Phone),
case for xDSL or ISDN or Mobile Phone),
7.SATMODE performance closely matches end-user
requirements,
requirements,
8. SATMODE performance closely matches the interactive provider
and TV bouquet provider requirements:
and TV bouquet provider requirements:
·Always-on,
·Sufficient QoS,
·Provide very low
communication cost for the service provider,
·Enable the generation of
new 'Telco' revenue,
·Enable the generation of
premium rate fee,
9. Allows the bypassing of existing expensive Telecommunication
companies,
companies,
10. potential to improve the security of
CA system
11. The installation of the ODU is as simple as the installation
ofcurrent dishes.
From the end user's point of view,
the following benefits can be derived from SATMODE
12. The main functions of a satellite modem are modulation and
demodulation. .
Popular modulation types being used
for satellite communications:
·Quadrature phase shift
keying
·Orthogonal quadrature
phase shift keying (
·8PSK
·Quadrature amplitude
modulation (especially 16QAM. )
·Binary phase shift keying
13. Error correction codes and formats.
·Convolution codes
· constraint length(less
than 10, usually decoded using a Viterbi algorithm
·constraint length more than 10, usually decoded using a Fano
algorithm
·Reed-Solomon codes usually
concatenated with convolutional codes with an interleaving
·New modems support
superior error correction codes (turbo codes )
SATMODE gets rid of the need to
connect the Set-Top-Box to a PSTN line, thus removing an obstacle to using
interactive applications,
SATMODE eliminates the conflict
between simultaneous voice and interactive TV connections,
SATMODE
provides an 'always on' connection.
From the broadcaster's point of view, such a return channel leads to
substantial revenue increase: churn reduction, incomes from new services,
interactive advertisement, piracy control, etc. SATMODE provides a scalable,
universal solution, integrated with the TV satellite infrastructure. It also
provides access to the end user Set-Top-Box for statistics, audience
measurement and Personal Video Recorder management, etc.
FUTURE
New features Enhanced conditional access Audience metering Statistics
gathering Hard disk drive content
management .Non broadcast applications may include tele-surveillance and
process monitoring .Interactivity enabled by the ASTRA return link will greatly
enhance future applications such as video-on-demand, messaging, gaming and
growing audience interaction in various types of shows. Interactive television
is a way to increase revenue for broadcasters of both pay-TV and free-to-air
programming. Revenues are generated through the use of votes, games, messages,
gambling and impulse pay-per -view. Interactive television also increases the
quality of the entertainment experience by inviting individual involvement.
This, in turn, attracts new viewers and reduces churn. To maximize these
revenues, permanent connection between the set-top box and the provider is
essential. ASTRA is a leading partner in the development of such connectivity:
the SATMODE project, a satellite return system for interactive TV that connects
individual TV viewers with their content providers. It is planned that SATMODE
will be implemented in ASTRA homes as an additional revenue generation tool.
CONCLUSION
SATMODE is currently in the latter stages of development The SATMODE
system is set to enable permanent, real time responses by millions of TV
viewers to content provider’s programmes.The system could also be exploited for
anonymous statistic gathering, and especially for management of content on the
set-top boxes equipped with a Personal Video recorder (PVR). SATMODE program
comprises the development of an ultra low cost satellite interactive system,
which includes all required activities, including commercial field trial
.Although compatible with existing satellites; SATMODE is designed to be ready
for new generations of space segments. SATMODE is a low cost interactive TV
solution via satellite, targeting the mass-market through consumer products
No comments:
Post a Comment
leave your opinion
